Point out key Kubernetes metrics and log elements to help you troubleshoot and tune Docker and Kubernetes
Managing microservices in containers is typically done with Cluster Managers and Orchestration tools such as Google Kubernetes, Apache Mesos, Docker Swarm, Docker Cloud, Amazon ECS, Hashicorp Nomad just to mention a few. However, each platform has slightly different of options to deploy containers or schedule tasks to each cluster node. This is why we started a Series of blog post with Docker Swarm Monitoring, and continue today with a quick tutorial for Container Monitoring and Log Collection on Kubernetes.
Docker is all the rage these days, but one doesn’t hear about running Solr on Docker very much.
Last month, we gave a talk on the topic of running containerized Solr at the Lucene Revolution conference in Boston, the biggest open source conference dedicated to Apache Lucene/Solr. The 40-minute talk included a live demo that shows how to actually do it, while addressing a number of important bits if you want to run Solr on Docker in production.
Curious to check the presentation? You may find it below.
Or, interested in listening to the 40-minute talk? Check it below.
Needless to say, monitoring Solr is essential in production and Docker is disruptive in many ways, and there are many things that are slightly different and worth mentioning. For instance, one can create, deploy, and run applications by using containers and this gives a significant performance boost and reduces the size of the applications.
In the context of centralizing logs (say, to Logsene or your own Elasticsearch), we often get the question of whether one should log directly from the application (e.g. via an Elasticsearch or syslog appender) or use a dedicated log shipper.
In this post, we’ll look at the advantages of each approach, so you’ll know when to use which.
Most programming languages have libraries to assist you with logging. Most commonly, they support local files or syslog, but more “exotic” destinations are often added to the list, such as Elasticsearch/Logsene. Here’s why you might want to use them:
Convenience: you’ll want a logging library anyway, so why not go with it all the way, without having to set up and manage a separate application for shipping? (well, there are some reasons below, but you get the point)
Fewer moving parts: logging from the library means you don’t have to manage the communication between the application and the log shipper
Lighter: logs serialized by your application can be consumed by Elasticsearch/Logsene directly, instead of having a log shipper in the middle to deserialize/parse it and then serialize it again
Your log shipper can be Logstash or one of its alternatives. A logging library is still needed to get logs out of your application, but you’ll only write locally, either to a file or to a socket. A log shipper will take care of taking that raw log all the way to Elasticsearch/Logsene:
Reliability: most log shippers have buffers of some form. Whether it tails a file and remembers where it left off, or keeps data in memory/disk, a log shipper would be more resilient to network issues or slowdowns. Buffering can be implemented by a logging library too, but in reality most either block the thread/application or drop data
Performance: buffering also means a shipper can process data and send it to Elasticsearch/Logsene in bulks. This design will support higher throughput. Once again, logging libraries may have this functionality too (only tightly integrated into your app), but most will just process logs one by one
Enriching: unlike most logging libraries, log shippers often are capable of doing additional processing, such as pulling the host name or tagging IPs with Geo information
Fanout: logging to multiple destinations (e.g. local file + Logsene) is normally easier with a shipper
Design-wise, the difference between the two approaches is simply tight vs loose coupling, but the way most libraries and shippers are actually implemented are more likely to influence your decision on sending data to Elasticsearch/Logsene:
logging directly from the library might make sense for development: it’s easier to set up, especially if you’re not (yet) familiar with a log shipper
in production you’ll likely want to use one of the available log shippers, mostly because of buffers: blocking the application or dropping data (immediately) are often non-options in a production deployment
If logging isn’t critical to your environment (i.e. you can tolerate the occasional loss of data), you may want to fire-and-forget your logs to Logsene’s UDP syslog endpoint. This takes reliability out of the equation, meaning you can use a shipper if you need enriching or support for other destinations, or a library if you just want to send the raw logs (which may well be JSON).
Shippers or libraries, if you want to send logs with anything that can talk to Elasticsearch or syslog, you can sign up for Logsene here. No credit card or commitment is required, and we offer 30-day trials for all plans, in addition to the free ones.
If, on the other hand, you enjoy working with logs, metrics and/or search engines, come join us: we’re hiring worldwide.
This is a guest post by Nedim Šabić, developer of Fibratus, a tool for exploration and tracing of the Windows kernel.
Unlike Linux / UNIX environments which provide a plethora of open source and native tools to instrument the user / kernel space internals, the Windows operating systems are pretty limited when it comes to diversity of tools and interfaces to perform the aforementioned tasks. Prior to Windows 7, you could use some of not so legal techniques like SSDT hooking to intercept system calls issued from the user space and do your custom pre-processing, but they are far from efficient or stable. The kernel mode driver could be helpful if it wouldn’t require a digital signature granted by Microsoft. Actually, some tools like Sysmon or Process Monitor can be helpful, but they are closed-source and don’t leave much room for extensibility or integration with external systems such as message queues, databases, endpoints, etc.
Now seriously, applications tend to generate a lot more logs on Black Friday, and they also tend to break down more – making those logs even more precious. If you’re using the Elastic Stack for centralized logging, in this post we’ll share some tips and tricks to prepare you for this extra traffic.
If you’re still grepping through your logs via ssh, doing that on Black Friday might be that more painful, so you have two options:
get started with the Elastic Stack now. Here’s a complete ELK howto. It should take you about an hour to get started and you can move on from there. Don’t forget to come back to this post for tips! 🙂
The big question here is: can the pipeline easily max out Elasticsearch, or will it become the bottleneck itself? If your logs go directly from your servers to Elasticsearch, there’s little to worry about: as you spin more servers for Black Friday, your pipeline capacity for processing and buffering will grow as well.
You may get into trouble if your logs are funnelled through one (or a few) Logstash instances, though. If you find yourself in that situation you might check the following:
Bulk size. The ideal size depends on your Elasticsearch hardware, but usually you want to send a few MB at a time. Gigantic batches will put unnecessary strain on Elasticsearch, while tiny ones will add too much overhead. Calculate how many logs (of your average size) make up a few MB and you should be good.
Number of threads sending data. When one thread goes through a bulk reply, Elasticsearch shouldn’t be idling – it should get data from another thread. The optimal number of threads depends on whether these threads are doing something else (in Logstash, for example, pipeline threads also take care of parsing, which can be expensive) and on your destination hardware. As a rule of thumb, about 4 threads with few things to do (e.g. no grok or geoip in Logstash) per Elasticsearch data node should be enough to keep them busy. If threads have more processing to do, you may need more of them.
The same applies for processing data: many shippers work on logs in batches (recent versions of Logstash included) and can do this processing on multiple threads.
Distribute the load between all data nodes. This will prevent any one data node from becoming a hotspot. In Logstash specify an array of destination hosts. Or, you can start using Elasticsearch “client” nodes (with both node.data and node.master set to false in elasticsearch.yml) and point Logstash to two of those (for failover).
The same applies for the shipper sending data to the central Logstash servers – the load needs to be balanced between them. For example, in Filebeat you can specify an array of destination Logstash hosts or you can use Kafka as a central buffer.
Make sure there’s enough memory to do the processing (and buffering, if the shipper buffers in memory). For Logstash, the default 1GB of heap may not cope with heavy load – depending on how much processing you do, it may need 2GB or more (monitoring Logstash’s heap usage will tell for sure).
Refresh interval. There’s an older blog post on how refresh interval influences indexing performance. The conclusions from it are still valid today: for Black Friday at least, you might want to relax the real-time-ness of your searches to get more indexing throughput.
Async transaction log. By default, Elasticsearch will fsync the transaction log after every operation (2.x) or request (5.x). You can relax this safety guarantee by setting index.translog.durability to async. This way it will fsync every 5s (default value for index.translog.sync_interval) and save you some precious IOPS.
Size based indices. If you’re using strict time-based indices (like one index every day), Black Friday traffic may cause a drop in indexing throughput like this (mainly because of merges):
In order to continue writing at that top speed, you’ll need to rotate indices before they reach that “wall size”, which is usually at 5-10GB per shard. The point is to rotate when you reach a certain size, and not purely by time, and use an alias to always write to the latest index (in 5.x this is made easier with the Rollover Index API).
Ensure load is balanced across data nodes. Otherwise some nodes will become bottlenecks. This requires your number of shards to be proportional to the number of data nodes. Feel free to twist Elasticsearch’s arm into balancing shards by configuring index.routing.allocation.total_shards_per_node: for example, if you have 4 shards and one replica on a 4-data-node cluster, you’ll want a maximum of 2 shards per node.
Overshard so you can scale out if you need to, while keeping your cluster balanced. You’d do this by setting a [reasonable] number of shards that has enough divisors. For example, if you have 4 data nodes then 12 shards and 1 replica per shard might work well. You could scale up to 6, 8, 12 or even 24 nodes and your cluster will still be perfectly balanced.
Relax the merge policy. This will slow down your full-text searches a bit (though aggregations would perform about the same), use some more heap and open files in order to allow more indexing throughput. 50 segments_per_tier, 20 max_merge_at_once and 500mb max_merged_segment should give you a good boost.
Don’t store what you don’t need. Disable _all and search in specific fields (and search in “message” or some other general field by default via index.query.default_field to it). Skip indexing fields not used for full-text search and skip doc values for fields on which you don’t aggregate.
Use doc values for aggregations (instead of the in-memory field data) – this is the default for all fields except analyzed strings since 2.0, but you’ll need to be extra careful if you’re still on 1.x. Otherwise you’ll risk running out of heap and crash/slow down your cluster.
Use dedicated masters. This is also a stability measure that helps your cluster remain consistent even if load makes your data nodes unresponsive.
You’ll find even more tips and tricks, as well as more details on implementing the above, in our Velocity 2016 presentation. But the ones described above should give you the most bang per buck (or rather, per time, but you know what they say about time) for this Black Friday.
Tuning & scaling Elasticsearch isn’t rocket science, but it often requires time, money or both. So if you’re not into taking care of all this plumbing, we suggest delegating this task to us by using Logsene, our log analytics SaaS. With Logsene, you’d get:
The same Elasticsearch API when it comes to indexing and querying. We have Kibana, too, in addition to our own UI, plus you can use Grafana Elasticsearch integration.
Free trials for any plan, even the Black Friday-sized ones. You can sign up for them without any commitment or credit card details.
A lot of extra goodies on top of Elasticsearch, like role-based authentication, alerting and integration with SPM for your application monitoring. This way you can have your metrics and logs in one place.
If, on the other hand, you are passionate about this stuff and work with it, you might like to hear that we’re hiring worldwide, on a wide range of positions (at the time of this writing there are openings for backend, frontend (UX, UI, ReactJS, Redux…), sales, work on Docker, consulting and training). 🙂
This is a guest post by Prof. Chanwit Kaewkasi, Docker Captain who organized Swarm3K – the largest Docker Swarm cluster to date.
Swarm3K was the second collaborative project trying to form a very large Docker cluster with the Swarm mode. It happened on 28th October 2016 with more than 50 individuals and companies joining this project.
Sematext was one of the very first companies that offered to help us by offering their Docker monitoring and logging solution. They became the official monitoring system for Swarm3K. Stefan, Otis and their team provided wonderful support for us from the very beginning.
To my knowledge, Sematext is one and the only Docker monitoring company which allow to deploy the monitoring agents as the global Docker service at the moment. This deployment model provides for a greatly simplified the monitoring process.
Swarm3K Setup and Workload
There were two planned workloads:
MySQL with WordPress cluster
The 25 nodes formed a MySQL cluster. We experiences some mixing of IP addresses from both mynet and ingress networks. This was the same issue found when forming a cluster of Apache Spark in the past (see https://github.com/docker/docker/issues/24637). We prevented this by binding the cluster only to a single overlay network.
A WordPress node was scheduled somewhere on our huge cluster, and we intentionally didn’t control where it should be. When we were trying to connect a WordPress node to the backend MySQL cluster, the connection kept timing out. We concluded that a WordPress / MySQL combo would be set to run correctly if we put them together in the same DC.
We aimed for 3000 nodes, but in the end we successfully formed a working, geographically distributed 4,700-node Docker Swarm cluster.
What we also learned from this issue was that the performance of the overlay network greatly depends on the correct tuning of network configuration on each host.
When the MySQL / WordPress test failed, we changed the plan to try NGINX on Routing Mesh.
The Ingress network is a /16 network which supports up to 64K IP addresses. Suggested by Alex Ellis, we then started 4,000 NGINX containers on the formed cluster. During this test, nodes were still coming in and out. The NGINX service started and the Routing Mesh was formed. It could correctly serve even as some nodes kept failing.
We concluded that the Routing Mesh in 1.12 is rock solid and production ready.
We then stopped the NGINX service and started to test the scheduling of as many containers as possible.
This time we simply used “alpine top” as we did for Swarm2K. However, the scheduling rate was quite slow. We went to 47,000 containers in approximately 30 minutes. Therefore it was going to be ~10.6 hours to fill the cluster with 1M containers. Unfortunately, because that would take too long, we decided to shut down the manager as it made no point to go further.
Scheduling with a huge batch of containers stressed out the cluster. We scheduled the launch of a large number of containers using “docker scale alpine=70000”. This created a large scheduling queue that would not commit until all 70,000 containers were finished scheduling. This is why when we shut down the managers all scheduling tasks disappeared and the cluster became unstable, for the Raft log got corrupted.
One of the most interesting things was that we were able to collect enough CPU profile information to show us what was keeping the cluster busy.
Here we can see that only 0.42% of the CPU was spent on the scheduling algorithm. I think we can say with certainty:
The Docker Swarm scheduling algorithm in version 1.12 is quite fast.
I would like to thanks Sematext again for the best-of-class Docker monitoring system, DigitalOcean for providing all resources for huge Docker Swarm managers, and the Docker Engineering team for making this great software and supporting us during the run.
While this time around we didn’t manage to launch all 150,000 containers we wanted to have, we did manage to create a nearly 5,000-node Docker Swarm cluster distributed over several continents. Lessons we’ve learned from this experiment will help us launch another huge Docker Swarm cluster next year. Thank you all and I’m looking forward to the new run!
Many of our clients use AWS EC2. In the context of Elasticsearch consulting or support, one question we often get is: should we use AWS Elasticsearch Service instead of deploying Elasticsearch ourselves? The question is valid whether “self hosted” means in EC2, some other cloud or your own datacenter. As always, the answer is “it depends”, but in this post we’ll show how the advantages of AWS Elasticsearch compared to those of deploying your own Elasticsearch cluster. This way, you’ll be able to decide what fits your use-case and knowledge.
Why AWS Elasticsearch?
It automatically replaces failed nodes: you don’t need to get paged in the middle of the night, spin a new node and add it to the cluster
You can add/remove nodes through an API – otherwise you’ll have to make sure you have all the automation in place so that when you spin a node you don’t spend extra time manually installing and configuring Elasticsearch
You can manage access rights via IAM: this is easier than setting up a reverse proxy or a security addon (cheaper, too, if the addon is paid)
Daily snapshots to S3 are included. This saves you the time and money to set it up (and the storage cost) for what is a mandatory step in most use-cases
CloudWatch monitoring included. You will want to monitor your Elasticsearch cluster anyway (whether you build or buy)
Why to install your own Elasticsearch?
On demand equivalent instances are cheaper by ~29%. The delta differs from instance to instance (we checked m3.2xl and i2.2xl ones). You get even more discount for your own cluster if you use reserved instances
More instance types and sizes are available. You can use bigger i2 instances than AWS Elasticsearch, and you have access to the latest generation of c4 and m4 instances. This way, you are likely to scale further and get more bang per buck, especially with logs and metrics (more specific hardware recommendations and Elasticsearch tuning here)
You can change more index settings, beyond analysis and number of shards/replicas. For example, delayed allocation, which is useful when you have a lot of data per node. You can also change the settings of all indices at once by hitting the /_settings endpoint. By properly utilizing various settings Elasticsearch makes available you can better optimize your setup for your particular use case, make better use of underlying resources, and thus drive the cost down further.
You can change more cluster-wide settings, such as number of shards to rebalance at once
You get access to all other APIs, such as Hot Threads, which is useful for debugging
You can use a more comprehensive Elasticsearch monitoring solution. Currently, CloudWatch only collects a few metrics, such as cluster status, number of nodes and documents, heap pressure and disk space. For most use-cases, you’ll need more info, such as the query latency and indexing throughput. And when something goes wrong, you’ll need more insight on JVM pool sizes, cache sizes, Garbage Collection or you may need to profile Elasticsearch
You can have clusters of more than 20 nodes
You may see a pattern emerging from the bullets above: AWS Elasticsearch is easy to set up and comes with a few features on top of Elasticsearch that you’ll likely need. However, it’s limited when it comes to scaling – both in terms of number&size of nodes and Elasticsearch features.
If you already know your way around Elasticsearch, AWS Elasticsearch service will likely only make sense for small clusters. If you’re just getting started, you can go a longer way until it will start to pay off for you to boost your knowledge (e.g. via an Elasticsearch training) and install your own Elasticsearch cluster (maybe with the help of our consulting or support). Or you can delegate the whole scaling part to us by using Logsene, especially if your use-case is about logs or metrics.
Finally, if you think there are too many “if”s in the above paragraph, here’s a flowchart to cover all the options:
Our colleagues Radu Gheorghe and Rafał Kuć were present in Amsterdam and gave a talk about: Elasticsearch for logs and metrics: A deep dive. And it was a great experience!They met with web operations and DevOps professionals interested in improving their Elastic Stack skills.
Lots of comments and questions were answered!
Curious to check their presentation? You may find it below.
Not everyone uses Splunk or ELK stack for logs. A few weeks ago, at the Lucene/Solr Revolution conference in Boston, we gave a talk about using Solr for logging, along with lots of good info about how to tune the logging pipeline. The talk also goes over the best AWS instance types, optimal EBS setup, log shipping (see Top 5 Logstash Alternatives), and so on.
SPM provides Akka monitoring via Kamon and has been doing that for quite a while now. With SPM and Kamon you get out of the box metrics about Akka Actors, Dispatchers and Routers, about the JVMs your Akka app runs in, and system metrics.
We’ve recently made a few nice improvements that should be of interest to anyone using Akka, and especially those using Play! Framework.
We’ve expanded our Transaction Tracing support and now support Kamon’s Traces and Trace Segments. Note that Traces don’t necessarily have to be initiated by an HTTP request. SPM’s Transaction Tracing lets you specify where a transaction starts. You can see that in our Demo Akka App, which is not actually a web app, so we specified where in code its transactions start and end. Traces can be produced by instrumentation libraries like ‘kamon-play’ or manually in the code using something like this:
val tContext = Kamon.tracer.newContext("name")
And for segments:
val segment = tContext.startSegment("some-section", "business-logic", "kamon")
// your code that is a part of this transaction would be here
So what exactly do these Akka monitoring reports look like? Here are some examples:
